Mori Seiki SL 25 specifications and buying considerations for CNC turning shops
Why the Mori Seiki SL 25 still matters in used CNC turning
The Mori Seiki SL 25 remains relevant for shops that need a rigid, mid-size used CNC turning center in the 10-inch chuck class, with practical bar capacity and a familiar Fanuc-based control architecture. It is not a current-production machine. Specifications vary by year, control package, installed options and model suffix, so any listing should be treated as a starting point, not the final technical authority.
For manufacturers comparing legacy equipment, the SL 25 is best understood as a durable two-axis turning platform for general production, shaft work, bushings, hydraulic components and job-shop parts. On machines of this age, mechanical condition and documentation usually matter more than the nameplate alone.
For more machinery guides and equipment notes, visit the Machines section.
Core specifications to verify before comparing listings
Public auction sheets, used machinery listings and model research pages commonly describe the Mori Seiki SL 25 and SL-25B family as mid-size CNC lathes built around a geared spindle, hydraulic chuck, turret and, on many machines, a programmable or hydraulic tailstock. The same model name, however, can appear with different bed lengths, turret configurations and control generations. Before comparing prices, verify the machine plate, serial number, manuals, control type and actual option list.
| Item | Commonly reported range or configuration | What to verify |
|---|---|---|
| Machine type | Two-axis CNC lathe or turning center | Confirm whether it is a basic SL 25, SL-25B, SL-25M, SL-25MC, SL-25Y or another suffix |
| Chuck class | Often listed with a 10 in hydraulic chuck | Check actual chuck brand, jaw stroke, drawtube condition and maximum safe rpm |
| Turning diameter | Many SL-25B/500 listings show around 10.2 in or about 260 mm | Confirm the swing, tool interference and turret clearance for your part family |
| Turning length | Often around 20 to 21 in for the 500 mm class | Distinguish maximum turning length from distance between centers |
| Spindle speed | Many SL-25B machines are listed up to 3500 rpm, while some SL 25 configurations differ | Run the spindle through each gear range and check noise, vibration and orientation |
| Spindle bore and bar capacity | Spindle bore is often reported near 3.1 in, with usable bar capacity commonly in the mid-2 in range | Measure the actual liner, drawtube and collet or chuck setup |
| Turret | Common examples show 10 or 12 stations depending on version | Test index repeatability, clamp pressure and every station under load |
| Control | Fanuc 0T, Fanuc 10T, Mori MF-T series and Mori MSC/Fanuc-based controls appear in listings | Confirm parameters, backup media, screen condition, memory, communication ports and alarms |
| Weight and footprint | Listings vary from roughly 4.2 metric tons to heavier configurations with conveyor and options | Plan rigging, floor loading, door clearance and electrical service before purchase |
The key point is straightforward: the Mori Seiki SL 25 name identifies the machine class, not the complete configuration. A clean SL-25B/500 with manuals, parameters, a healthy spindle and a working tailstock may be more valuable to a production shop than a poorly documented machine with more accessories.
Variant names that can confuse buyers
Searches for mori seiki sl 25 often return several related names. Some refer to actual machine variants. Others point to later or different models that should not be treated as interchangeable.
SL 25 and SL-25B
The base SL 25 and SL-25B are the names most buyers associate with the conventional two-axis turning center. The B suffix is common in used listings, especially for SL-25B/500 machines. These models are typically evaluated as general-purpose CNC lathes rather than modern multitasking machines.
SL-25B/500 and SL-25B/1000
The number after the slash normally indicates the bed or working length class. A 500 mm class machine is more compact and commonly appears with turning lengths around the low-20-inch range. A 1000 mm class machine is longer and should be inspected with extra attention to ballscrew condition, way wear, tailstock alignment and support for longer workpieces.
SL-25M, SL-25MC and SL-25Y
M, MC or Y suffixes may indicate added capability such as milling, C-axis or Y-axis functions, depending on the exact machine. These suffixes matter because tooling, programming, maintenance and market value are different from a simple two-axis lathe. Do not assume live tooling or Y-axis travel unless the machine, control screens and option list confirm it.
SL 25 versus SL 250
The SL 250 is not simply another spelling of SL 25. Used machinery databases often show both names, and confusion is common because the numbers look similar. If a quotation, manual or parts inquiry mixes SL 25 and SL 250, verify the serial number and model plate before ordering parts or planning a process.
Where the Mori Seiki SL 25 fits in a modern shop
The SL 25 is most attractive where the work calls for rigidity, stable turning and straightforward operation rather than the newest control features. It can make sense for job shops, repair operations and manufacturers that already understand older Fanuc-style controls and need a lathe for moderate-diameter work.
Typical applications include pins, shafts, bushings, threaded components, bearing housings, hydraulic fittings, spacers and short-to-medium production runs. This machine class is also useful for roughing work where a geared spindle and heavier construction are more important than very fast acceleration.
Its limits are just as important. A standard two-axis SL 25 is not a substitute for a modern Y-axis turning center, a Swiss-type lathe or a high-speed automated cell. Controls from this generation may have limited memory, older displays, serial communication requirements and fewer convenience features. Safety guarding, coolant containment and documentation may also fall short of what a modern factory expects unless the machine has been refurbished.
For a shop with experienced CNC lathe operators, those limits may be manageable. For a shop building its first turning department, the learning curve can be higher than expected, especially if the machine arrives without parameters, ladder documentation, electrical drawings or working communication hardware. See also: Materials.
Inspection checklist for a used Mori Seiki SL 25
Condition is the real value driver. Inspect the machine under power whenever possible. A static warehouse inspection can confirm general appearance, but it cannot prove spindle health, turret repeatability, axis behavior or control reliability.
- Spindle and gearbox: Run the spindle through low and high ranges. Listen for gear noise, bearing rumble and vibration. Check warm-up behavior and verify that the spindle reaches commanded speeds.
- Axis motion: Jog X and Z across their travel. Look for stick-slip, following errors, lubrication alarms, backlash and abnormal servo load.
- Turret indexing: Index every station repeatedly. Confirm clamp and unclamp action, station alignment and toolholder fit.
- Tailstock: If equipped, test body travel, quill movement and center alignment. Tailstock issues can quickly affect shaft work and drilling accuracy.
- Hydraulics and lubrication: Inspect pumps, hoses, pressure switches, metering units and visible way lubrication. Old hydraulic hoses and weak pumps are common age-related risks.
- Control and parameters: Confirm that the machine boots cleanly, holds parameters, communicates through its available port and has a recent backup.
- Coolant and chip handling: Check tanks, conveyor operation, sheet metal, leaks and coolant pump function. These items may look secondary, but they affect daily usability.
- Documentation: Manuals, ladder prints, parameter lists, alarm records and maintenance notes reduce commissioning risk.
A cutting test is more useful than a showroom video. If possible, turn a test bar, measure taper over length, check surface finish and repeat a simple bore or OD operation. This provides practical evidence of alignment, rigidity and control behavior under real load.
How to compare it with newer turning centers
A used Mori Seiki SL 25 can be attractive because the purchase price is usually far below that of a new CNC turning center. That does not automatically make it cheaper to own. A fair comparison should include the total cost of use: rigging, electrical work, repairs, lost time, tooling, training, coolant management and future parts availability.
Newer lathes generally offer faster rapids, more efficient motors, better guarding, easier networking, larger program storage, current safety systems and support for modern automation. They may also provide live tooling, Y-axis capability, sub-spindles or conversational programming that can remove secondary operations.
The SL 25 can still compete when the work is simple turning, the machine is mechanically sound and the shop can support older controls. Its strength is not digital convenience; it is the combination of mass, proven mechanical design and enough capacity for many everyday turned parts. The wrong machine, however, can turn into a restoration project. A low asking price should never outweigh missing parameters, spindle problems or a turret that will not repeat.
Frequently asked questions
Is the Mori Seiki SL 25 still a good CNC lathe?
It can be a good used CNC lathe if the individual machine is mechanically healthy, properly documented and suited to the work. Age alone does not disqualify it, but spindle condition, control reliability, lubrication and turret repeatability are critical.
What control does the Mori Seiki SL 25 use?
Different machines appear with different Fanuc-based or Mori-labeled controls, including Fanuc 0T, Fanuc 10T, MF-T series and MSC-series controls. The exact control should be verified from the machine panel, electrical cabinet and manuals, not assumed from the model name.
What is the typical chuck size on an SL 25?
Many used SL 25 and SL-25B listings show a 10-inch hydraulic chuck, often from suppliers such as Kitagawa. Actual chuck size, condition and safe speed should be checked directly because chucks may have been replaced during the machine life.
Should buyers choose an SL-25B/500 or a longer SL-25B/1000?
Choose based on part length, floor space and inspection results. The 500 mm class is more compact and easier to place, while a 1000 mm class machine supports longer work but adds alignment, footprint and rigging considerations.
What is the biggest risk when buying one?
The biggest risk is buying from photos or incomplete specifications. Missing parameter backups, worn spindle bearings, turret alignment problems, hydraulic faults and undocumented electrical changes can cost more than the initial discount appears to save.
Final takeaway
The Mori Seiki SL 25 is best viewed as a capable legacy turning center, not a one-size-fits-all bargain. For the right shop, a documented and well-maintained machine can provide practical turning capacity with familiar controls and robust construction. For the wrong shop, or when the machine has hidden mechanical or control issues, it can become expensive downtime. Verify the exact variant, test the machine under power, measure a real cut and judge the purchase by condition, documentation and process fit.
